Solenoid valve
>> Details:
?/strong>Technical Specifications ?/strong>
-- Media: Water, Steam, Oil (below 20cst)
--Function type: Normally Closed (N/C), Normally Open (N/O)
----Pressure: Normally Closed 16 bar, Normally Open 8bar
--Temperature: -5 180?
--Mode of action: Pilot operated
--Body material: Brass
-- Sealing material: PTFE
--Protection class: IP54
OPTIONS
Viton (V): suitable to hot water, acid, alkali, chemical salt, oil and hydrocarbon;
the MAX.150? In case you choose Viton, please state ?in your order.
And the coil protection class is IP65.
How to order
Valve type | Connection pipe size | Connection | Function type | Voltage |
ZCLF | ---15 |
| K | ---DC:24V |
15 40 | Blank : Thread | Blank: N/C | AC?20V | |
| 20 50 | F: Flange | K: N/O | AC?10V |
| 25 |
|
| DC:24V |
| 32 |
|
| DC:12V |
PARAMETERS?/strong>N/C?/strong>
Model | ZCLF-15 | ZCLF-20 | ZCLF-25 | ZCLF-32 | ZCLF-40 | ZCLF-50 | |
G Connection | 1/2" | 3/4" | 1" | 1" | 1" | 2" | |
Orifice Size | mm | 15 | 20 | 25 | 32 | 40 | 40 |
Cv Value | 5.2 | 8.5 | 15.3 | 20.4 | 31 | 51 | |
L | mm | 80 | 100 | 110 | 135.5 | 131 | 141 |
H | mm | 150 | 156 | 165 | 192 | 200 | 210 |
H1 | mm | 129 | 130 | 137 | 157 | 165 | 170 |
Medium temperature ? | -5 180? | ||||||
Pressure | bar | Normally Closed : 0.416 bar Normally Open: 0.4 8bar | |||||
Power | AC:220V~AC:230V/50-60HZ 41VA; AC110 ~AC:120V/50-60HZ 14VA; DC24 36 W; DC12 24W ; Range:10% | ||||||
