Product List
JLT Solenoid Valves2022/5/26 21:49:55
Product Specifications/Features :
1. Product Name: 4T and 2T Serial
2. Max Pressure: 4.5Bar/10Bar/15Bar
3. Nominal Diameter: 2.0mm/2.5mm/3.0mm
4. Connecting Size/Type:ZG1/8" Conical outlet / 4-M4.
Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
7. Fluid Temp: 140
8. Amb Temp80 120
9. Insulation class: H
JLT Solenoid Valves2022/5/26 21:49:55
1. Product Name: 2T Serial
2. Max Pressure: 4.5Bar/5.5Bar/10Bar/15Bar
3. Nominal Diameter: 2.0mm/2.2mm/2.3mm/2.5mm/3.0mm
4. Connecting Size/Type: Intubation Type/ ZG1/8" Conical
outlet / G1/8" Pipe inlet
5. Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
7. Fluid Temp: 140
8. Amb Temp80 120
JLT Solenoid Valves2022/5/26 21:49:56
1. Product Name: 3T Serial
2. Max Pressure: 10Bar/15Bar/18Bar
3. Nominal Diameter: 0.8/1.0mm/1.5mm/2.0mm/2.5mm
4. Connecting Size/Type: ZG1/8" Conical outlet / G1/8" Pipe
inlet
5. Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
7. Fluid Temp: 140
8. Amb Temp80 120
9. Insulation class: H
JLT Solenoid Valves2022/5/26 21:49:56
1. Product Name: 3T Serial
2. Max Pressure: 10Bar/15Bar/18Bar
3. Nominal Diameter: 0.8/1.0mm/1.5mm/2.0mm/2.5mm
4. Connecting Size/Type: ZG1/8" Conical outlet / G1/8" Pipe
inlet
5. Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
7. Fluid Temp: 140
8. Amb Temp80 120
9. Insulation class: H
JLT Solenoid Valves2022/5/26 21:49:57
1. Product Name: 2T Serial
2. Max Pressure: 4.5Bar/5.5Bar/10Bar/15Bar
3. Nominal Diameter: 2.0mm/2.2mm/2.3mm/2.5mm/3.0mm
4. Connecting Size/Type: Intubation Type/ ZG1/8" Conical
outlet / G1/8" Pipe inlet
5. Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
8. Amb Temp80 120
9. Insulation clas
JLT Solenoid Valves2022/5/26 21:49:57
1. Product Name: 2T Serial
2. Max Pressure: 4.5Bar/5.5Bar/10Bar/15Bar
3. Nominal Diameter: 2.0mm/2.2mm/2.3mm/2.5mm/3.0mm
4. Connecting Size/Type: Intubation Type/ ZG1/8" Conical
outlet / G1/8" Pipe inlet
5. Action Method: Direct action and normally closed.
6. Working Medium: Water, Steam, Air.
7. Fluid Temp: 140
8. Amb Temp80 120
